Tube Bender
Technical Parameter of Tube Bender
1. outer diameter: OD219mm,325mm,426mm
2. The maximum thickness: 18mm,25mm,40mm
3. Angle of bend: 180degree,180degree,180degree
4. Relative bend radius: 3D~6D,3D~6D,3D~6D
5. The maximum stroke of main cylinder: 2.5m 3.5m 4.5m
6. The working pressure of hydraulic pressure system:10Mpa 10Mpa 10Mpa
Main components of Tube Bender
Main machine body
Heating coils bracket
Radius rail
Big rotating arm
Small rotating arm
Main clamping apparatus
Main clamping apparatus
Hydraulic system Electrical system
Welcome to Heiyan visit.Our company supply other product: Tube Bender,PLC pipe bending machine, pipe expanding machine,bevel machine,we also supply special specification machine according to customers requirements.
Your demand,our reliability.
