Elbow machine
Intermediate frequency induction heating hydraulic propulsion Elbow Machine is our traditional products.In recent years, with the factory pipeline equipment processing technology development,this product has got the profound derivation tuning. At present,we produce elbow pushed system machine, has integrated ultrashort stress line cone die hole enlargement technology,digital frequency conversion mid-frequency induction heating technology and no back pressure, low consumption,hydraulic transmission technology to form machine, realizing hydraulic push board gate open and close, raw material tube of hydraulic clamping was under multiple operations, and combined with the mechanized innovation. Based on 2 steps propulsion pipe-pushing machine innovation and development of new patent,developed four cylinder elbow push system new product.
1 Elbow Machine is suitable for various kinds of gases, liquids conveying pipeline engineering,meeting bend pipe demand.
2 Raw material for elbow machine: Seamless steel tube, welded tube and rolled steel tube,carbon steel pipe, alloy steel etc. The products according to bend the diameter of the size consists of 8 specification, the range of products: outside diameter 2 inches (50mm) - 40 inches (1200mm) wall thickness 5mm~120mm. Angle ranges 22.5 degree,45 degree, 90 degree,135 degree and according to customer demand. Also according to the customer request,make different specifications of the elbow pushed system machine.HYW hydraulic elbow machine structure and working principle
According to the customer's demand of diameter and wall thickness,this equipment structure set intermediate frequency heating power, oil cylinder diameter and stroke, and oil cylinder quantity.
Factory made equipment is of: Hydraulic elbow machine,hydraulic pressure station and moderate frequency power,electrical control cabinet,work station,compensation resonant capacitor ark, water cable, reactor unit etc.Based on the specifications of the goods ,users shall be separately procure:intermediate frequency induction heating coil, mandrel.This equipment working principle: Put prepared raw materials on the mandrel in the head,put medium frequency induction on the steel tube of elbow push, open cooling water pump,open moderate frequency power heating the raw material pipe to 800 degree,open elbow macine, which can easily push elbows.
Middle-frequency induction heater, medium frequency induction heating coil, compensation capacitor, water cable, reactor unit etc all needs circulating through water cooling.Elbow machine have stroke switch for each end, realizing positioning parking, reversing.
Welcom to visit Hei Yan Group for HYW elbow machine,and pipe bending machine.
please call us ,If you have any question .
