325mm Hot Bending Machine
1. Specification:OD325*17.46mm (Max bending diameter:OD325mm,Thickness:17.46mm)
Bending scope: OD89-OD325mm Bending radius:3-9D
2.
325mm Hot Bending Machine main cylinder(2pcs): Cylinder inside OD:160mm,Total pushing force:85T
Stroke 3500mm as per 325mm 9D
Hydraulic system max pressure:21Mpa
3.Medium frequency of 325mm Hot Bending Machine
Medium frequency power:30-350kw(Energy save digital control,soft start)
Frequency:500-1000Hz
Control circuit adopts CPLD full digital process control, output pulse stable,on time,high touch power, high anti-interference,automatically adjust operating data, feedback signal auto adjust X angle and F angle,to achieve part energy save,low errors,zero pressure scan soft start.
Transformer:1000-1200KVA
Welcome to Heiyan visit.Our company supply other product:325mm Hot Bending Machine,PLC pipe bending machine, pipe expanding machine,bevel machine,we also supply special specification machine according to customers requirements.
