1200 Ton Four Cylinder Elbow Pushing Machine
Main technical data
1.1200 Ton Four Cylinder Elbow Pushing Machine technical data
Main cylinder: Inside OD:390mm Outside OD485mm,stroke:8m
Four cylinder ,Max. pushing power:1432 T, working Max. pushing power:1200T
Theoretical Pushing speed:620mm/min Return speed:1210mm/min
Max. produced elbow: OD 1067*55 Material : A335 P22.
Pump generator power:45KW-6 1set,18.5KW-4 1set ,18.5KW-4 2sets,15Kw-6 1set, 7.5KW-6 1set
2. Operation of the 1200 Ton Four Cylinder Elbow Pushing Machine
Operating procedures are as following:
According to the elbow size select the main pushing pump-- As per the elbow size select the speed -- feeding, close gate --After the mandril been heated to a suitable temperature begin pushing (during working the pushing speed is adjustable) -Reaching the end point ,pushing machine stop automatically- Strobe fix the core rod -- feeding -- release the strobe, pushing machine return to the end point -- strobe leave the core rod 5mm starting pushing.
Hei Yan Int'L Development Limted has been in the line for many years, with our experience and professional engineer, we can design Products according to customers requires.
If you are interested in our product,please feel free to contact us.Heiyan also supply 1200 Ton Four Cylinder Elbow Pushing Machine,Elbow Machine,Bevel Machine,Medium Frequency. Welcome to our factory visit.
