Hydraulic Cylinder Tube Expander
Hydraulic Cylinder Tube Expander is composed of the host mechanical system, hydraulic system and intermediate frequency heating system. Among these systems, full-automatic hydraulic feeding machine, and counterparts machine are franchised patent products.
The specifications of the Hydraulic Cylinder Tube Expander that we can supply:
1. Production range: OD108mm-1200mm
2. Thickness: 6mm-80mm
3. Material: Carbon steel, Alloy steel
4. Drive type: Hydraulic
Hydraulic Cylinder Tube Expander Features Description
1. The supporting plate, pushing plate of the machine is formed by 20mm medium plate welding ,the center hole diameter is 350mm.
2. Pushing plate and supporting plate strobe all used hydraulic control .
Note: In order to improve efficiency, the pushing plate strobe also was changed to the hydraulic control .
3. The main hydraulic valve parts adopt international standards Rexroth Products (Beijing Hua De), solenoid valves are controlled by DC 24V .
4. Anterior supporting plate is equipped with clip pipe fittings.
5. Each side of Support plate, pushing plate, gate, gate slide are all processed with planer milling
6. Supporting plate gate and pushing plate gate all used 45 # steel plate.
Welcome to visit Hei Yan for more information of the Hydraulic Cylinder Tube Expander. We also supply other products of Bevel Machine,Pipe Bending Machine,Tee Machine,Elbow Fitting Machine. If you are interested in our products,please contact us.
