Mandrel Elbow Pushing Machine
material of producing elbows: seamless steel pipe, welded steel pipe and rolled steel pipe. The range of the elbow that our Mandrel elbow Pushing machine can produce is as following:
OD: 1 inch (25mm)- 60 inches (1420mm);
Thickness: 5mm - 120mm;
angle: 22.5 degree 45 degree 90 degree 135 degree and the angle of user needs
Operation
Operating procedures of Mandrel Elbow Pushing Machine are as following:
According to the elbow size select the main pushing pump-- As per the elbow size select the speed -- feeding, close gate --After the mandril been heated to a suitable temperature begin pushing (during working the pushing speed is adjustable) -Reaching the end point ,pushing machine stop automatically- Strobe fix the core rod -- feeding -- release the strobe, pushing machine return to the end point -- strobe leave the core rod 5mm starting pushing
Note: 1, Main pump can be used the same time when working, in general, using one.
2, Return pump can not be used the same time, only one start and one spare.
3, Feed pump can be used only when feeding .
4, Main cylinder ,make the safe pressure at 25Mpa,make the attached cylinder safe pressure at 10MPa.
Welcome to contact with us for Mandrel Elbow Pushing Machine, we also manufacture pipe expanding machine,pipe bending machine,medium frequency heating equipment according to customer requirement.
